FEP tubing F46 hose plastic flexible pipe

FEP tube dispersion resins via paste extrusion temperature sintering pipes, excellent resistance to high temperature, abrasion resistance, corrosion resistance, electrical properties, with no adhesion.

It is widely used in electric coated, anti-corrosion, insulating sheath sheath, and conveying gases, liquids catheter and automobile throttle lasso casing, spraying coating equipment, etc

It is suitable for national defense, chemical, pharmaceutical, oil, electronics, communications, textile, automotive, aerospace household electrical appliances, etc. Made of 100% virgin FEP resin

Main features:

*  Wide operating temperature-85 °C to 200 °C;

*  Non-stick, non-toxic, water proof and oil proof;

*  Electricity reliability, high insulation 60HZ-60MHZ both high and low temperature dielectric constant 2.1. Even if  the surface due to flash over and the damage it does not produce conductive tracks. Volume resistance> 1018Ωm Surface resistance> 2 X 1013Ω Arc> 165 seconds without leakage;

*  Excellent resistance to solvents and chemicals:
Corrosion resistance Only high temperature element fluorine, alkali metals and it works on all the other thick, dilute inorganic acids, alkalis, esters      had no effect.

*  Low water absorption Low suction rate of <0.01% Incombustibility The air will not burn. (Oxygen index> 95vol.%)

*  Transparency Optical refractive index in the lowest of all plastics Weatherability Can be prolonged exposure to ozone, the sun Easy processing of secondary Can be self-appointed, self-welding can be flange, it can be set to control

Usage:

LCD manufacturing equipment
Single fiber light-emitting whole body single-ended tube
Heat exchangers, steam piping
High-purity reagents
Pipeline A variety of corrosive media (harsh solvents) pipeline
Submersible motor with a slot insulation tube
Air-conditioning control wiring harness assembly,

All-inclusive fluoride O-ring plastic tube.
